Thursday, October 25, 2018, 6:00 PM - 9:30 PM SGT
Pipeline production system often experiences complex multiphase flow and entrained fine-particles. The erosion due to solid fine particles presents one of the greatest threats to oil and gas flow assurance and consequently impacting material selection and wall thickness design. Limited literature is available on erosional effect caused by submicron particles such as fine sand, abrasive solid materials or gas bubbles. Previous studies on particles’ erosion are limited to particle size greater than 100 microns in single phase fluid flow. This is based on the assumption that potential for erosion by particle size smaller than 100 microns (specifically lesser than 62.5 microns) is insignificant. Additionally, very few studies have addressed the combined effect of erosion caused by micro-sized particles and multiphase flow.
Most predictive erosion models are limited to single phase flow for model simplification purposes. Hence, the effects of multiphase flow and its interaction with sand particles, specifically fine solids, are neglected. Therefore, an in-depth understanding of multiphase flow regimes and its interaction with micro-sized particles is an important enabler for more accurate erosion prediction. For more accurate flow modeling and erosion characterization, computer fluid dynamics (CFD) tool is required. In this study, Multiphase CFD (MCFD) is implemented for predicting micro-fine erosion, considering two phase flow pattern features. Concurrently, trajectories of fine particles’ bombardment on the pipe inner wall surface are captured using Lagrangian Particle Tracking Model. Analyses are carried out for water and gas flow at isothermal conditions, covering various particle size lesser than 62.5 microns in order to determine material removal rate. The results will be benchmarked against Tulsa multiphase erosion model prediction.
Based on the results, it is concluded that the erosional effect caused by micro-sized particles is strongly dependent on the flow patterns in the pipe, determined by superﬁcial velocities of each phase. Additionally, erosional impact or material removal rate is predicted, which though small, is expected to significantly impact material design. The presence of these micro-sized particles acts as an enabler, which produces homogeneous “pits” on the surface of metal, significantly increasing the contact surface area for chemical and mechanical interactions to take place. The results from the proposed modeling using MCFD are expected to benefit erosion impact assessment in multiphase hydrocarbon production and piping systems.
Keywords- Erosion Analysis, Submicron Particles, Fines, Multiphase CFD, Flow Pattern Features
Ngo Nguyet Tran is currently a Flow Assurance Engineer with WorleyParsons - INTECSEA division, based in Singapore. She earns a B.Eng (Hons) in Petroleum Engineering and M.Sc. in Mechanical Engineering – Flow Assurance Study from Universiti Teknologi PETRONAS, Malaysia. She has over four years’ experience in transient multiphase flow and flow assurance related issues. Other technical experience in subsurface-surface modeling and CFD modeling. She is a member of the SPE Singapore Section Committee.
